Overview
The LoadForce TA100 mechanical brake caliper is a durable, reliable option for mechanical disc brake setups on trailers and caravans. Made from galvanized cast iron, this side-neutral unit fits ½" to ⅝" (12–15 mm) thick rotors and includes premium asbestos-free brake pads, stainless slide tubes, and anti-rattle clips. It replaces ARK CM100G and suits many boat and box trailer brake systems
✅ Key Features
-
Assembled and retail packaged with high-spec brake pads
-
Premium galvanised housing—excellent corrosion resistance
-
Designed for ½″–⅝″ rotor thickness compatibility
-
Stainless slide pins and anti-rattle clips for smooth operation
-
Heavy-duty asbestos-free friction pads that resist brake fade under high heat
-
Australian trailer standard load capability (approx. 1,300 kg with 13″/14″ rims or ~1,000 kg with 15″/16″ rims)
-
Most common mounting bolt pattern—2 × A100BOLT required (not included)
📋 Specifications
| Specification | Detail |
|---|---|
| Model | TA100 Mechanical Caliper |
| Material | Galvanized Cast Iron |
| Rotor Compatibility | ½″–⅝″ thick disc (approx. 12–15 mm) |
| Brake Pads | Included, asbestos-free |
| Slide Pins | Stainless steel |
| Anti-Rattle Clips | Included |
| Compatible with | ARK CM100G, Trigg & mechanical disc systems |
| Required Mount Bolts | 2 × A100BOLT (sold separately) |
