Overview
The EBS.BL.JOIN brass brake line joiner is a robust three-way connector designed for 3/16″ inverted-flare brake tubing. With three 3/8″ UNF female thread ports, it allows you to branch one feed line into two outputs—perfect for tandem-axle hydraulic brake installations.
🔧 Key Features
-
Solid brass construction for strength, corrosion resistance, and long service life
-
Uses 3/8″ UNF 24 TPI female threads, compatible with standard trailer brake hoses and rigid tubing
-
Includes a mounting hole for chassis attachment, ensuring reliable positioning and strain relief
⚙️ Technical Specifications
| Feature | Specification |
|---|---|
| Part Number | EBS.BL.JOIN |
| Material | Brass |
| Thread Size | 3/8″ UNF Female (24 TPI) |
| Tube Type | Designed for 3/16″ (4.75 mm) inverted-flare brake tube |
| Mounting Feature | Integrated chassis mounting hole |
| Warranty | 12-month manufacturer warranty |
🚚 Applications
-
Split brake line routing for tandem-axle setups
-
Joining hydraulic brake feed to multiple wheels without rigid joints
-
Ideal for flexible stainless brake hoses or traditional copper-brass rigid brake lines
-
Suitable for trailers, boat trailers, caravans, and DIY brake system installations
🔍 Why Include This Joiner?
This brass joiner provides a compact, leak-resistant junction for branching brake lines. Unlike welded steel tees or flexible unions, it installs easily with standard fittings and maintains DOT/SAE compliance. It also supports hose mount fixation, improving durability and ease of routing.
🛠 Installation Tips
-
Thread into brake hose port finger-tight; then torque to spec—avoid over-tightening.
-
Secure to chassis using the mounting hole to reduce movement.
-
Use compatible hose or rigid lines with inverted-flare ends and 3/8″ UNF fittings.
-
Always pressure-test after plumbing installation to ensure no leaks occur.
