LED AUTOLAMPS 150 SERIES LED LIGHTS
P/N: 150BAR2
Features / Specifications
- Premium Trailer Lamp
- Diamond Pattern Lens
- Low Profile
- ADR approved
- IP67 100% Water proof
- Voltage Range 12V or 12-24V
- Lifetime Warranty
- 150mm x 80mm x 24mm
Fitting Instructions
Surface mount onto flat surface vertically with Indicator at top using bolts in back of lamp, run wire and plug through 10mm hole in fixing surface. Please refer to ADR 13/00 for mounting instructions.
| LED Qty | 14 | ||
| Cable | 40cm with Plug | ||
| Draw | Stop | Tail | Ind |
| @13.8V | 0.13A | 0.04A | 0.12A |
| @28V | 0.12A | 0.06A | 0.07A |
| Approvals | Function | Category | CRN |
| ADR | Stop/Tail | 49/00 | 37381 |
| ADR | Indicator | 6/00 2a | 37380 |
| ADR | Reflector | 47/00 | 38102 |
