Brass 3‑Way Brake Line Joiner – 3/16″ Flare / 3/8″ UNF Female Threads | DOT/SAE Compatible

EBS.BL.JOIN
Regular price
$12.00
Sale price
$12.00
Unit price
per
Tax included.
🚚 Fast Shipping Australia-wide
Most orders dispatch next business day from QLD.
Shipping is calculated at checkout based on your location.
View full shipping info

Overview

The EBS.BL.JOIN brass brake line joiner is a robust three-way connector designed for 3/16″ inverted-flare brake tubing. With three 3/8″ UNF female thread ports, it allows you to branch one feed line into two outputs—perfect for tandem-axle hydraulic brake installations.


🔧 Key Features

  • Solid brass construction for strength, corrosion resistance, and long service life

  •  Uses 3/8″ UNF 24 TPI female threads, compatible with standard trailer brake hoses and rigid tubing

  • Includes a mounting hole for chassis attachment, ensuring reliable positioning and strain relief


⚙️ Technical Specifications

Feature Specification
Part Number EBS.BL.JOIN
Material Brass
Thread Size 3/8″ UNF Female (24 TPI)
Tube Type Designed for 3/16″ (4.75 mm) inverted-flare brake tube
Mounting Feature Integrated chassis mounting hole
Warranty 12-month manufacturer warranty

🚚 Applications

  • Split brake line routing for tandem-axle setups

  • Joining hydraulic brake feed to multiple wheels without rigid joints

  • Ideal for flexible stainless brake hoses or traditional copper-brass rigid brake lines

  • Suitable for trailers, boat trailers, caravans, and DIY brake system installations


🔍 Why Include This Joiner?

This brass joiner provides a compact, leak-resistant junction for branching brake lines. Unlike welded steel tees or flexible unions, it installs easily with standard fittings and maintains DOT/SAE compliance. It also supports hose mount fixation, improving durability and ease of routing.


🛠 Installation Tips

  1. Thread into brake hose port finger-tight; then torque to spec—avoid over-tightening.

  2. Secure to chassis using the mounting hole to reduce movement.

  3. Use compatible hose or rigid lines with inverted-flare ends and 3/8″ UNF fittings.

  4. Always pressure-test after plumbing installation to ensure no leaks occur.
